Tolu Fittings is a well-respected manufacturer and supplier of top-notch pipe fittings based in Abuja, Nigeria. We specialize in crafting both 180° Long Radius and 180° Short Radius Elbows. Our dedication to precision engineering and high-quality materials means that our elbows are not only durable but also resistant to corrosion, making them perfect for efficient fluid flow across a variety of industrial applications. We utilize cutting-edge technology to ensure our products meet both local and international standards, guaranteeing reliability, strength, and a long lifespan. Tolu Fittings proudly serves sectors such as oil and gas, petrochemical, construction, and water treatment throughout Nigeria and beyond.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless 180° Long Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 180° Long Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 180° Long Radius Elbow
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless 180° Short Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 180° Short Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 180° Short Radius Elbow
The 180 Degree Long Radius and Short Radius Elbows are typically constructed from stainless steel, carbon steel, alloy steel, and other specialized materials. This thoughtful composition provides outstanding resistance to heat, corrosion, and pressure, even in demanding environments. These elbows boast impressive tensile strength, high yield strength, and remarkable hardness, which contribute to their mechanical stability. The long radius elbows facilitate smoother flow transitions with reduced friction, while the short radius versions are perfect for tight installations where space is at a premium. Both types are designed to withstand thermal and mechanical stress, ensuring exceptional toughness.
Stainless Steel 45° Long Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 45° Long Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 45° Long Radius Elbow : ASTM A420 WPL3, A420 WPL6
Stainless Steel 180° Short Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 180° Short Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 180° Short Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 180° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 180° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 180° Short Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 180° Short Radius Elbow : ASTM A420 WPL3, A420 WPL6
Tolu Fittings is a leading supplier of 180 Deg Long Redius Elbow and 180 Deg Short Redius Elbow in Abuja, Nigeria. We offer an extensive range of 180 Deg Long Redius Elbow and 180 Deg Short Redius Elbow, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Our 180° Long Radius and Short Radius Elbows are made from premium materials like carbon steel, stainless steel, and alloy steel, tailored to meet our clients’ specific needs. These fittings boast impressive tensile strength, toughness, and resistance to both corrosion and high pressure. They typically feature high yield strength, flexibility through elongation, and superior hardness for wear resistance. Even in extreme temperature and pressure conditions, these elbows maintain their structural integrity, making them ideal for demanding industrial settings that require reliable flow direction and pressure management.
The 180° Long Radius and Short Radius Elbows from Tolu Fittings are crucial components in various piping systems that need smooth directional flow. They’re commonly used in industries such as oil and gas, petrochemical, power generation, water supply, and chemical processing. Long radius elbows are perfect for situations where space allows, as they help reduce friction and pressure loss, while short radius elbows are designed for tighter spaces. Both types effectively change the flow direction by 180 degrees, ensuring optimal fluid dynamics and maintaining the integrity of pipelines transporting gas, steam, water, or other fluids.
Yes, custom sizes for 180 Deg Long Redius Elbow and 180 Deg Short Redius Elbow are available at Tolu Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@tolufittings.com.
| NPS | O.D. D | 90 degrees Long Radius Center-to-End A | 45 degrees Long Radius Center-to-End B | 90 degrees 3D Center-to-End A | 45 degrees 3D Center-to-End B |
| 1/2 | 21.3 | 38 | 16 | – | – |
| 3/4 | 26.7 | 38 | 19 | 57 | 24 |
| 1 | 33.4 | 38 | 22 | 76 | 31 |
| 1 ¼ | 42.2 | 48 | 25 | 95 | 39 |
| 1 ½ | 48.3 | 57 | 29 | 114 | 47 |
| 2 | 60.3 | 76 | 35 | 152 | 63 |
| 2 ½ | 73 | 95 | 44 | 190 | 79 |
| 3 | 88.9 | 114 | 51 | 229 | 95 |
| 3 ½ | 101.6 | 133 | 57 | 267 | 111 |
| 4 | 114.3 | 152 | 64 | 305 | 127 |
| 5 | 141.3 | 190 | 79 | 381 | 157 |
| 6 | 168.3 | 229 | 95 | 457 | 189 |
| 8 | 219.1 | 305 | 127 | 610 | 252 |
| 10 | 273 | 381 | 159 | 762 | 316 |
| 12 | 323.8 | 457 | 190 | 914 | 378 |
| 14 | 355.6 | 533 | 222 | 1067 | 441 |
| 16 | 406.4 | 610 | 254 | 1219 | 505 |
| 18 | 457 | 686 | 286 | 1372 | 568 |
| 20 | 508 | 762 | 318 | 1524 | 632 |
| 22 | 559 | 838 | 343 | 1676 | 694 |
| 24 | 610 | 914 | 381 | 1829 | 757 |
| 26 | 660 | 991 | 406 | 1981 | 821 |
| 28 | 711 | 1067 | 438 | 2134 | 883 |
| 30 | 762 | 1143 | 470 | 2286 | 964 |
| 32 | 813 | 1219 | 502 | 2438 | 1010 |
| 34 | 864 | 1295 | 533 | 2591 | 1073 |
| 36 | 914 | 1372 | 565 | 2743 | 1135 |
| 38 | 965 | 1448 | 600 | 2896 | 1200 |
| 40 | 1016 | 1524 | 632 | 3048 | 1264 |
| 42 | 1067 | 1600 | 660 | 3200 | 1326 |
| 44 | 1118 | 1676 | 695 | 3353 | 1389 |
| 46 | 1168 | 1753 | 727 | 3505 | 1453 |
| 48 | 1219 | 1829 | 759 | 3658 | 1516 |
These elbows play a crucial role in piping systems, allowing for a 180-degree change in fluid flow direction. They are essential in sectors like oil and gas, chemical processing, shipbuilding, power plants, and water distribution systems. Long radius elbows are favored for applications requiring low friction and smooth fluid movement, while short radius elbows are ideal for compact layouts. By ensuring reliable performance, these elbows help minimize pressure drops and boost the efficiency and lifespan of intricate pipeline networks.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
