Tolu Fittings is a trusted manufacturer and supplier of 90° Long Radius Elbows in Abuja, Nigeria, offering top-quality fittings built for smooth flow, strength, and long-term reliability. These elbows are used to change the direction of piping by 90 degrees, providing a gradual curve that reduces friction, pressure drop, and flow resistance. Crafted from premium materials like stainless steel, carbon steel, or alloy steel, 90° Long Radius Elbows from Tolu Fittings are known for their durability, precision, and excellent performance in demanding environments. They’re the preferred choice for industries that value efficiency and reliability in their piping systems.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless 90° Long Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 90° Long Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 90° Long Radius Elbow
90° Long Radius Elbows are made from high-quality materials such as stainless steel, carbon steel, or alloy steel to suit various industrial applications. These fittings offer superior mechanical strength, excellent resistance to corrosion, and the ability to withstand high pressure and temperature. The long radius design (1.5 times the nominal pipe diameter) ensures smoother flow and minimizes erosion and turbulence inside the pipeline. They possess strong tensile and yield strength, great weldability, and dimensional accuracy, ensuring consistent performance and long service life.
Stainless Steel 90° Long Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 90° Long Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 90° Long Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 90° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 90° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 90° Long Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 90° Long Radius Elbow : ASTM A420 WPL3, A420 WPL6
Tolu Fittings is a leading supplier of 90 Deg Long Redius Elbow in Abuja, Nigeria. We offer an extensive range of 90 Deg Long Redius Elbow, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose 90 Deg Long Redius Elbow from Tolu Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
90° Long Radius Elbows are widely used in industries such as oil & gas, petrochemical, power generation, water treatment, and construction. They are ideal for pipelines that transport liquids, gases, or steam over long distances where minimal flow resistance is critical. These elbows are also used in refineries, chemical plants, and HVAC systems for efficient direction changes without causing pressure loss. Tolu Fittings supplies 90° Long Radius Elbows that combine durability, precision, and efficiency—helping Nigerian industries build reliable, high-performance piping networks that stand the test of time.
Yes, custom sizes for 90 Deg Long Redius Elbow are available at Tolu Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@tolufittings.com.
| LONG RADIUS ELBOWS (R = 1,5 ND) ANSI B 16.9 dimensions | ||||||
| inches | ND | mm | Center to center | Radius | Center to end | Back to face |
| D | O | A | B | K | ||
| 1/2 | 15 | 21,34 | 76,20 | 38,10 | 15,87 | 47,62 |
| 3/4 | 20 | 26,67 | 57,15 | 28,57 | 11,11 | 42,86 |
| 1 | 25 | 33,40 | 76,20 | 38,10 | 22,22 | 55,56 |
| 1 1/4 | 32 | 42,16 | 95,25 | 47,60 | 25,40 | 69,85 |
| 1 1/2 | 40 | 48,26 | 114,30 | 57,15 | 28,57 | 82,55 |
| 2 | 50 | 60,32 | 152,40 | 76,20 | 34,92 | 106,40 |
| 2 1/2 | 65 | 73,02 | 190,50 | 95,25 | 44,45 | 131,80 |
| 3 | 80 | 88,90 | 228,60 | 114,30 | 50,80 | 158,75 |
| 3 1/2 | 90 | 101,60 | 266,70 | 133,35 | 57,15 | 184,15 |
| 4 | 100 | 114,30 | 304,80 | 152,40 | 63,50 | 209,55 |
| 5 | 125 | 141,30 | 381,00 | 190,50 | 79,38 | 261,90 |
| 6 | 150 | 168,27 | 457,20 | 228,60 | 95,25 | 312,70 |
| 8 | 200 | 219,07 | 609,60 | 304,80 | 127,00 | 414,30 |
| 10 | 250 | 273,05 | 762,00 | 381,00 | 158,75 | 517,50 |
| 12 | 300 | 323,85 | 914,40 | 457,20 | 190,50 | 619,10 |
| 14 | 350 | 355,60 | 1066,80 | 533,40 | 222,25 | 711,20 |
| 16 | 400 | 406,40 | 1219,20 | 609,60 | 254,00 | 812,80 |
| 18 | 450 | 457,20 | 1371,60 | 685,80 | 285,74 | 914,40 |
| 20 | 500 | 508,00 | 1524,00 | 762,00 | 317,50 | 1016,00 |
| 22 | 550 | 558,80 | 1676,40 | 838,20 | 342,90 | 1117,60 |
| 24 | 600 | 609,60 | 1828,80 | 914,40 | 381,00 | 1219,20 |
| 28 | 700 | 711,20 | 2133,60 | 1066,80 | 441,90 | 1422,40 |
| Dimensions in mm. | ||||||
90° Long Radius Elbows are widely used in various industrial applications to facilitate smooth directional changes in piping systems. They are commonly employed in oil and gas pipelines, chemical processing, power generation, and water treatment facilities to ensure efficient flow with minimal pressure loss. Their gradual bend design reduces the risk of erosion and maintains optimal flow rates. These elbows are also essential in HVAC systems and marine applications, providing durability and resistance to corrosion in high-pressure and high-temperature environments.
