Tolu Fittings is a reliable **Alloy 20 Buttweld Fittings Manufacturer and Supplier in Abuja, Nigeria**. We specialize in crafting high-quality piping solutions for industries that require exceptional corrosion resistance and durability. Our Alloy 20 Buttweld Fittings are designed to excel in tough chemical environments, utilizing advanced manufacturing techniques and rigorous quality standards. We offer a full range of fittings, including elbows, reducers, tees, and caps, perfect for both high-temperature and high-pressure applications. With a strong commitment to precision, reliability, and customer satisfaction, Tolu Fittings has become a go-to partner in Nigeria’s chemical, petrochemical, and power sectors.
| 20 Pipe Fittings Specifications | ASTM B366/ ASME SB366 |
|---|---|
| Alloy 20 Pipe Fittings size | 20 Seamless Butt Weld Fittings : 1/2″ – 10″ 20 Welded Butt Weld Fittings : 1/2″ – 48″ |
| Alloy 20 Pipe Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| Alloy 20 Buttweld Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| 20 Buttweld Pipe FittingsType | DN15-DN1200 |
| ASTM B366 20 Buttweld Fitting Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM B366 Alloy 20 Pipe Fitting |
| Size Range | ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM B366 20 Buttweld Fitting |
| ASTM B366 20 Buttweld Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| Alloy 20 Buttweld Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| SA 366 20 Pipe Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | Alloy UNS N08020, 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
**Alloy 20 Buttweld Fittings** are primarily made up of nickel (32–38%), chromium (19–21%), iron, molybdenum (2–3%), copper (3–4%), and niobium for stabilization. This unique blend provides remarkable resistance to sulfuric acid, phosphoric acid, and chloride stress corrosion cracking. On the mechanical side, Alloy 20 boasts a tensile strength of about 620 MPa and a yield strength of roughly 300 MPa, ensuring excellent formability and durability. These fittings also retain toughness and ductility at both room and elevated temperatures, making them ideal for critical environments where stainless steel might fall short in corrosion resistance.
| Grade | C | Mn | Si | S | Cu | Ni | Cr | Fe | Mo | P |
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 3.00 – 4.00 | 32.00 – 38.00 | 19.00 – 21.00 | 29.85 min* | 2.00 – 3.00 | 0.045 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
Tolu Fittings is a leading supplier of Alloy 20 Buttweld Fittings in Abuja, Nigeria. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | EN | AFNOR |
| Alloy 20 | 2.4660 | N08020 | NiCr20CuMo | Z2NCUD31-20AZ |
Alloy 20 Buttweld Fittings from Tolu Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
**Alloy 20 Buttweld Fittings** from **Tolu Fittings in Abuja, Nigeria**, are widely utilized in industries that deal with corrosive and acidic substances. They’re perfect for applications in chemical processing, pharmaceuticals, food and beverage, petrochemical plants, and power generation facilities. Common applications include pipelines for sulfuric acid, nitric acid, and other aggressive chemical solutions. Their exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking makes them a reliable choice for demanding environments.
| Standard Code | Standard Name |
| ANSI ASME SA-366 | Forged Durimet pipe fittings |
| ANSI ASME B16.9 | Factory-Made wrought steel pipe fittings |
| ANSI ASME B16.28 | Wrought steel butt-welding short radius elbows and returns |
| ISO 5251 | Alloy butt-welding fittings |
| MSS SP-43 | Wrought Alloy butt-welding fittings |
| MSS SP-75 | Forging butt-welding fittings |
| German Steel Pipe Fittings Standard | |
| DIN 2605 | Steel butt-welding pipe fittings.elbows and bends |
| DIN 2615 | Steel butt-welding pipe fittings.tees |
| DIN 2616 | Steel butt-welding pipe fittings.reducers |
| DIN 2617 | Steel butt-welding pipe fittings.caps |
| Japanese Steel Pipe Fittings Standard | |
| JIS B2311 | Universal steel butt-welding pipe fittings |
| JIS B2312 | Steel butt-welding pipe fittings |
| JIS B2313 | Steel plate butt-welding pipe fittings |
| Other Steel Pipe Fittings Standard | |
| EN 1025 | 3 Butt-welding pipe fittings |
Yes, custom sizes for Alloy 20 Buttweld Fittings are available at Tolu Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@tolufittings.com.
**Alloy 20 Buttweld Fittings** from **Tolu Fittings in Abuja, Nigeria**, are widely utilized in industries that deal with corrosive and acidic substances. They’re perfect for applications in chemical processing, pharmaceuticals, food and beverage, petrochemical plants, and power generation facilities. Common applications include pipelines for sulfuric acid, nitric acid, and other aggressive chemical solutions. Their exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking makes them a reliable choice for demanding environments.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
