Tolu Fittings, a well-respected manufacturer and supplier located in Abuja, Nigeria, specializes in high-quality Duplex Steel S32205 Pipe Fittings that are built for outstanding strength, durability, and resistance to corrosion. These fittings are crafted using cutting-edge technology and top-notch duplex stainless steel, ensuring they perform exceptionally well even in tough industrial environments. Renowned for their remarkable resistance to pitting, crevice corrosion, and stress corrosion cracking, Tolu Fittings’ Duplex Steel S32205 Pipe Fittings adhere to international quality standards, making them perfect for sectors like oil and gas, petrochemical, marine, and power generation, where reliability and longevity are essential.
| Specifications Standard | ASTM A815 /ASME SA815 |
|---|---|
| Duplex 2205 Pipe Fittings Size Range | Welded Fittings: 1/2″ – 48″ Seamless Fittings: 1/2″ – 10″ |
| Connection | Welding |
| Type | DN15 to DN1200 |
| Origin & Mills | Indian, European, Korean, Japanese, Ukraine, USA, Russian |
| Radius of bending | R=3D, 1D, 8D, 10D, 5D, 2D, Custom MSS Sp-43, 6D |
| Duplex 2205 Pipe Fittings Manufacturing process | Forge, Press, Cast, Push etc. |
| Thickness | SCH10, SCH40, XS, SCH30, SCH 160, SCH 80, SCH 140, SCH60, SCH20, STD , SCH 120, SCH 100, XXS |
| Pressure Ratings | 2000#, 150#, 6000#, 3000#, 9000# |
| End Connections: | socket weld and Threaded |
| Duplex 2205 Pipe Fittings manufacturer | 90º Tee, Elbows, Pipe Cap, Stub End, 45º Elbows, Crosses, Pipe Bend, Reducers |
| Dimensions | ASME B16.28, BS4504, MSS-SP-43, ASME/ANSI B16.9, BS1560, BS4504, BS10 |
| Elbows | Angle : 2.0D, 1.5D, 5D, 3D, 1.0D, 6D, 4D, 2.5D, 7D-40D . Standard: JISB2312, MSS SP-75, 22.5 deg, JISB2313, 30deg, ASME B16.9, 180 deg, 45 deg, JISB2311 BS, DIN2605, 90 deg, GB ISO |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate Third Party Inspection Report, etc |
The composition of Duplex Steel S32205 Pipe Fittings includes about 22% chromium, 5–6% nickel, 3% molybdenum, along with trace amounts of nitrogen, resulting in a well-balanced duplex microstructure of ferrite and austenite. They boast a high tensile strength of around 620 MPa and a yield strength of 450 MPa, along with excellent fatigue resistance and toughness. These fittings excel in resisting chloride-induced corrosion, oxidation, and erosion, all while maintaining impressive mechanical stability under high pressure and temperature.
| Grade | C | Mn | Si | N | P | Cr | Fe | Ni | S | Mo |
| S32205 Fittings | 0.030 maximum | 2.00 maximum | 1.00 maximum | 0.8 to 0.20 | 0.030 maximum | 21.0 to 23.0 | 63.54 minimum | 4.50 to 6.50 | 0.020 maximum | 2.50 to 3.50 |
| Grades | Density (lb/in 3) | Melting Point (°F) | Density (g/centimeter 3) | Melting Point (°C) |
| S32205 Fittings | 0.285 | 2588 to 2669 | 7.805 | 1420 to 1465 |
Tolu Fittings is a leading supplier of Duplex Steel S32205 Pipe Fittings in Abuja, Nigeria. We offer an extensive range of Duplex Steel S32205 Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Standard | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Super Duplex 2205 | 1.4462 | S32205 | – | – | – | – | – |
Duplex Steel S32205 Pipe Fittings from Tolu Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Duplex Steel S32205 Pipe Fittings offer numerous advantages, including exceptional corrosion resistance, especially in chloride-rich environments. Their high strength-to-weight ratio makes them ideal for demanding applications while reducing structural load. The alloy’s superior resistance to stress corrosion cracking (SCC) and pitting enhances durability in harsh conditions. Duplex Steel S32205 fittings also exhibit excellent weldability, ensuring reliable connections. With good formability and high toughness, they are well-suited for chemical, marine, and oil and gas industries, providing long-lasting performance and reducing maintenance needs.
| NOMINAL PIPE SIZE | ALL FITTINGS | ALL FITTINGS | 180 DEG RETURN BENDS | REDUCERS | ELBOWS AND TEES | 180 DEG RETURN BENDS | CAPS |
|---|---|---|---|---|---|---|---|
| NPS | ID at End (1), (3), (4) | OD at Bevel (1), (2) | Centre-to- Centre O | Overall Length H | Centre -to- End Dimension A, B, C, M | Alignment of Ends U | Overall Length E |
| ½ to 2½ | 0.003 | 0.006 -0.003 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 3 to 3 ½ | 0.006 | 0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 4 | 0.006 | 0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 5 to 8 | 0.006 | 0.009 -0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.025 |
| 10 to 18 | 0.012 | 0.016 -0.012 | 0.038 | 0.009 | 0.009 | 0.006 | 0.025 |
| 20 to 24 | 0.019 | 0.025 -0.019 | 0.038 | 0.009 | 0.009 | 0.006 | 0.025 |
| 26 to 30 | 0.019 | 0.025 -0.019 | … | 0.019 | 0.012 | … | 0.038 |
| 32 to 48 | 0.019 | 0.025 -0.019 | … | 0.019 | 0.019 | … |
Yes, custom sizes for Duplex Steel S32205 Pipe Fittings are available at Tolu Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@tolufittings.com.
Duplex Steel S32205 Pipe Fittings find extensive use in industries such as oil and gas, petrochemical, marine, and desalination plants. Their exceptional corrosion resistance makes them ideal for applications like pipelines, heat exchangers, pressure vessels, and offshore platforms that are regularly exposed to seawater and harsh chemicals. Additionally, these fittings are utilized in pulp and paper, power generation, and chemical processing sectors where high strength and durability are paramount. Their outstanding performance and reliability make them the go-to choice for critical and corrosive service environments.
