Hastelloy C22 Forged Fittings Manufacturer and Supplier In Abuja, Nigeria

Tolu Fittings, a trusted manufacturer and supplier based in Abuja, Nigeria, specializes in high-performance **Hastelloy C22 Forged Fittings** that offer outstanding resistance to corrosion, oxidation, and chemical attacks. These fittings are made from top-quality nickel-chromium-molybdenum-tungsten alloys, making them perfect for even the toughest industrial settings. Tolu Fittings guarantees that each forged fitting boasts superior strength, precise dimensions, and durability, making them ideal for critical applications in the chemical and marine sectors.

Hastelloy® Alloy C22 Forged Fittings Nigeria, Alloy C22 High Pressure Forged Fittings United kingdom, UNS N06022 Forged Fittings Abuja, Hastelloy C22 Socket weld Fittings Lagos, 2.4602 Forged Fittings Ibadan, C22 Hastelloy Forged Fittings Port Harcourt, Alloy C22 Threaded Fittings Kano, Hastelloy Alloy C22 Socket weld Fittings Nigeria.

Hastelloy C22 Forged Fittings Specification

C22 Forged Fittings Specifications	ASTM B564/ ASME SB564
Alloy C22 Forged Fittings size	1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Hastelloy C22 Forged Fittings Dimensions	ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Hastelloy C22 Forged Fittings Types	Socketweld Fittings, Screwed-Threaded Fittings
ASTM B564 C22 Hastelloy Forged Fittings Pressure Rating	Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs
Hastelloy C22 Forged Fittings Thread	NPT, BSPT, BSPP
C22 Hastelloy Forged Fittings Test Certificates	EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc
Nickel Alloy C22 Forged Fittings Origin & Mills	Japanese, Indian, USA, Korean, European, Ukraine, Russian
Specialized manufacturer of	90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plug

Hastelloy C22 Forged Fittings are made up of nickel (about 56%), chromium (around 22%), molybdenum (approximately 13%), tungsten (roughly 3%), along with trace amounts of iron and cobalt. This special combination provides excellent resistance to both oxidizing and reducing agents, along with robust protection against pitting and crevice corrosion. In terms of mechanical properties, these fittings have a tensile strength of about 690 MPa, a yield strength of around 310 MPa, and impressive ductility even under high-stress conditions.

Hastelloy C22 Forged Fittings Chemical Composition

Grade	C	Mo	Mn	Si	Fe	P	S	Co	Cr	W	V	Ni
C22	0.010	12.5 – 14.5	0.50	0.08	2.00 – 6.00	0.02	0.02	2.5	20 – 22.5	2.5 – 3.5	0.35	Bal

Hastelloy C22 Forged Fittings Mechanical Properties

Grade	Density	Melting Point	Yield Strength (0.2%Offset)	Tensile Strength	Elongation
C22	8.69 g/cm3	1399 °C (2550 °F)	Psi – 45000 , MPa – 310	Psi – 1,00,000 , MPa – 690	45 %

Largest Stockholder of Hastelloy® Alloy C22 Forged Fittings in Nigeria, Ready Stock of NiCr21Mo14W Hastelloy Forged Elbow United kingdom, C22 Hastelloy Forged Cross Trader Abuja, Competitive Price of Hastelloy C22 Forged Tees Lagos, Alloy C22 Coupling Ibadan, ASTM B564 C22 Socket weld Fittings Manufacturers in Port Harcourt, UNS N06022 Forged Fittings Kano, Hastelloy C22 Threaded Fittings Manufacturer in Abuja, Nigeria.

Hastelloy C22 Forged Fittings Equivalent

STANDARD	UNS	WERKSTOFF NR.	AFNOR	EN	JIS	BS	GOST
Hastelloy C22	N06022	2.4602	–	NiCr21Mo14W	NW 6022	–	–

Hastelloy C22 Forged Fittings Standards

Standard Code	Standard Name
ANSI ASME SB-564	Forged fittings
ANSI ASME B16.11	Socket-welding and Threaded forged fittings
MSS SP-79	Socket-welding reducing Inserts
MSS SP-83	Class 3000 steel socket-welding and threaded unions
MSS SP-95	Swaged nipples and round plugs
MSS SP-97	SW,TH and BW ends for integrally reinforced forged branch outlet

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Why Choose Hastelloy C22 Forged Fittings from Tolu Fittings?

Hastelloy C22 Forged Fittings from Tolu Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Hastelloy® Alloy C22 Forged Fittings Nigeria, Alloy C22 High Pressure Forged Fittings United kingdom, UNS N06022 Forged Fittings Abuja, Hastelloy C22 Socket weld Fittings Lagos, 2.4602 Forged Fittings Ibadan, C22 Hastelloy Forged Fittings Port Harcourt, Alloy C22 Threaded Fittings Kano, Hastelloy Alloy C22 Socket weld Fittings Nigeria.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Hastelloy C22 forged fittings offer several advantages, making them ideal for demanding applications. Their superior corrosion resistance protects against pitting, crevice corrosion, and stress corrosion cracking, even in aggressive environments like chlorine and acids. The alloy’s excellent weldability and formability ensure ease of fabrication, while its high strength and durability provide long-term reliability. Additionally, Hastelloy C22 maintains exceptional performance at elevated temperatures, making it suitable for a wide range of industrial applications. These properties make it a top choice for industries requiring highly resistant and durable fittings.

Types of Hastelloy C22 Forged Fittings

Are Custom Sizes Available for Hastelloy C22 Forged Fittings?

Yes, custom sizes for Hastelloy C22 Forged Fittings are available at Tolu Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@tolufittings.com.

Largest Stockholder of Hastelloy® Alloy C22 Forged Fittings in Nigeria, Ready Stock of NiCr21Mo14W Hastelloy Forged Elbow United kingdom, C22 Hastelloy Forged Cross Trader Abuja, Competitive Price of Hastelloy C22 Forged Tees Lagos, Alloy C22 Coupling Ibadan, ASTM B564 C22 Socket weld Fittings Manufacturers in Port Harcourt, UNS N06022 Forged Fittings Kano, Hastelloy C22 Threaded Fittings Manufacturer in Abuja, Nigeria.

Application Industry of Hastelloy C22 Forged Fittings

These Hastelloy C22 Forged Fittings find extensive use in various industries, including chemical processing, pharmaceuticals, marine engineering, and pollution control. They are particularly well-suited for applications that involve acidic gases, chlorides, and strong oxidizers. Common applications include heat exchangers, piping systems, pressure vessels, and reactors, where exceptional corrosion resistance, leak-proof performance, and structural integrity are crucial.
