Incoloy 825 Buttweld Fittings Manufacturer and Supplier In Abuja, Nigeria

Tolu Fittings, based in Abuja, Nigeria, has made a name for itself as a top-notch manufacturer and supplier of high-quality industrial fittings, with a special focus on Incoloy 825 Buttweld Fittings. These fittings, made from a nickel-iron-chromium alloy, are designed to provide outstanding corrosion resistance, durability, and strength even in the toughest conditions. They’re perfect for sectors like chemical processing, petrochemicals, power generation, and marine engineering. With their ability to resist acids, oxidation, and stress cracking, these fittings promise reliable, long-lasting performance. At Tolu Fittings, we pride ourselves on precision manufacturing, top-tier raw materials, and adherence to international quality standards, ensuring our fittings are trusted in critical industrial applications.

ANSI B16.9 Incoloy 825 Welded Buttweld Fittings Nigeria, Incoloy UNS N08800 Seamless Pipe Fittings United kingdom, Incoloy 3d Pipe Bend Abuja, Alloy 825 Short Radius Elbow Supplier Lagos, Incoloy 825 Pipe Fittings Ibadan, 825 Incoloy® Alloy Welded Pipe Fittings Dealer Port Harcourt, 825 Incoloy Alloy End Cap Kano, ASTM B366 825 Incoloy Alloy 90 degree Elbow Exporters and Suppliers in Nigeria, Incoloy 1.5d Pipe Bend United kingdom, 825 Incoloy Alloy End Cap Abuja, Incoloy WERKSTOFF NR1.4958 Cross Exporter in Port Harcourt.

Incoloy 825 Buttweld Fittings Specification

Grade	Incoloy Alloy 825 / UNS N08825
Standard	ASTM B366, ASME SB366
Dimensions	ASME B16.28, ASME/ANSI B16.9, MSS-SP-43
Incoloy 825 Seamless Fittings	1/2″ NB – 10″ NB
Incoloy 825 Welded Fittings	1/2″ NB – 48″ NB
Form	90 Elbow, 45 Elbow, Long Radius Elbow, Short Radius Elbow, Concentric Reducer, Eccentric Reducer, Equal Tee, Unequal Tee, Lateral Tee, Cross, Bends 1.5d, 3d, 5d, 10d, U bend, 180 Deg Bend, Short Stub End, Long stub end, End Cap, Dish Cap
Schedule	SCH 5 To SCH XXS
Wall Thickness	from 2 to 40 mm
Type	Seamless / Welded / Fabricated

Incoloy 825 Buttweld Fittings Chemical Composition

Ni	Fe	C	Mn	Si	Mb	Cu	Cr	Al	Ti	S
38.0 – 46.0	22.0 min	0.05 max	1.0 max	0.5 max	2.5 – 3.5	1.5 – 3.0	19.5 – 23.5	0.2 max	0.6 – 1.2	0.015 max

Incoloy 825 Buttweld Fittings Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.14 g/cm3	1400 °C (2550 °F)	Psi – 80,000 , MPa -550	Psi – 32,000 , MPa – 220	30 %

Incoloy 825 Buttweld Fittings are made up of nickel (38–46%), iron (the balance), and chromium (19–23%), along with trace amounts of molybdenum, copper, titanium, and aluminum. This well-balanced mix gives them excellent resistance to both oxidizing and reducing acids, especially sulfuric and phosphoric acids. On the mechanical side, these fittings boast high tensile and yield strength, remarkable toughness, and outstanding resistance to creep and stress rupture. The alloy remains structurally stable even in high-pressure and high-temperature settings. Crafted to exacting tolerances, Incoloy 825 Buttweld Fittings guarantee long-term dimensional accuracy, weldability, and reliability for demanding industrial tasks.

825 Incoloy Alloy End Cap Nigeria, Incoloy® Alloy 825 180 Deg bend United kingdom, Incoloy Alloy 825 Pipe Bend Abuja, Jis Ncf 825 Pipe Fittings Lagos, Incoloy Alloy 825 Stub Ends Ibadan, Incoloy 825 Pipe End Cap Port Harcourt, 825 Incoloy Alloy End Cap Kano, Incoloy® Alloy 825 Equal Tee Abuja, Ansi B16.9 800h Incoloy 45 / 90 / 180 Deg. Reducing Elbow Nigeria, Incoloy 825 Pipe Elbow Abuja, Supplier of Incoloy 825 45 degree Elbow Nigeria, Incoloy 10d Pipe Bend Lagos, 825 Incoloy Reducer, Incoloy® Alloy 825 Pipe bend Supplier in Nigeria.

Largest Incoloy 825 Buttweld Fittings Supplier in Abuja, Nigeria

Tolu Fittings is a leading supplier of Incoloy 825 Buttweld Fittings in Abuja, Nigeria. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Why Choose Incoloy 825 Buttweld Fittings from Tolu Fittings?

Incoloy 825 Buttweld Fittings from Tolu Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

ANSI B16.9 Incoloy 825 Welded Buttweld Fittings Nigeria, Incoloy UNS N08800 Seamless Pipe Fittings United kingdom, Incoloy 3d Pipe Bend Abuja, Alloy 825 Short Radius Elbow Supplier Lagos, Incoloy 825 Pipe Fittings Ibadan, 825 Incoloy® Alloy Welded Pipe Fittings Dealer Port Harcourt, 825 Incoloy Alloy End Cap Kano, ASTM B366 825 Incoloy Alloy 90 degree Elbow Exporters and Suppliers in Nigeria, Incoloy 1.5d Pipe Bend United kingdom, 825 Incoloy Alloy End Cap Abuja, Incoloy WERKSTOFF NR1.4958 Cross Exporter in Port Harcourt.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Incoloy 825 buttweld fittings offer several key advantages. Their exceptional resistance to a wide range of corrosive environments, including acids, seawater, and gases, makes them ideal for harsh industrial conditions. The alloy’s high nickel and chromium content ensures excellent stress corrosion cracking resistance and oxidation resistance. Incoloy 825 also provides superior weldability, allowing for easy fabrication and installation. With excellent mechanical properties, including high strength and durability, these fittings are perfect for use in industries such as chemical processing, oil and gas, and power generation, ensuring long-lasting and reliable performance.

Incoloy 825 Buttweld Fittings Dimensions

Nominal PipeSize	Outside Diameter		90° Elbows		45° Elbows		180° Returns
*(inches)*	–		Long Radius	Short Radius	Long Radius		Long Radius
	*(mm)*	*(inches)*	Center to Face (inches)	Center to Face (inches)	Center to Face (inches)	Radius (inches)	Center to Center (inches)	Back to face (inches)
1/2	21.3	0.840	1 1/2	–	5/8		2	1 7/8
3/4	26.7	1.050	1 1/8		7/16		2 1/4	1 11/16
1	33.4	1.315	1 1/2	1	7/8		3	2 3/16
1 1/4	42.2	1.660	1 7/8	1 1/4	1		3 3/4	2 3/4
1 1/2	48.3	1.900	2 1/4	1 1/2	1 1/8	3	4 1/2	3 1/4
2	60.3	2.375	3	2	1 3/8	4	6	4 3/16
2 1/2	73.0	2.875	3 3/4	2 1/2	1 3/4	5	7 1/2	5 3/16
3	88.9	3.500	4 1/2	3	2	6	9	6 1/4
3 1/2	101.6	4.000	5 1/4	3 1/2	2 1/4	7	10 1/2	7 1/4
4	114.3	4.500	6	4	2 1/2	8	12	8 1/4
5	141.3	5.563	7 1/2	5	3 1/8	10	15	10 5/16
6	168.3	6.625	9	6	3 3/4	12	18	12 5/16
8	219.1	8.625	12	8	5	12	24	16 5/16
10	273.1	10.750	15	10	6 1/4	15	30	20 3/8
12	323.9	12.750	18	12	7 1/2	18	36	24 3/8

Types of Incoloy 825 Buttweld Fittings

Are Custom Sizes Available for Incoloy 825 Buttweld Fittings?

Yes, custom sizes for Incoloy 825 Buttweld Fittings are available at Tolu Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@tolufittings.com.

825 Incoloy Alloy End Cap Nigeria, Incoloy® Alloy 825 180 Deg bend United kingdom, Incoloy Alloy 825 Pipe Bend Abuja, Jis Ncf 825 Pipe Fittings Lagos, Incoloy Alloy 825 Stub Ends Ibadan, Incoloy 825 Pipe End Cap Port Harcourt, 825 Incoloy Alloy End Cap Kano, Incoloy® Alloy 825 Equal Tee Abuja, Ansi B16.9 800h Incoloy 45 / 90 / 180 Deg. Reducing Elbow Nigeria, Incoloy 825 Pipe Elbow Abuja, Supplier of Incoloy 825 45 degree Elbow Nigeria, Incoloy 10d Pipe Bend Lagos, 825 Incoloy Reducer, Incoloy® Alloy 825 Pipe bend Supplier in Nigeria.

Application Industry of Incoloy 825 Buttweld Fittings

Incoloy 825 Buttweld Fittings find their place in various industries that require exceptional corrosion resistance and strength. You’ll often see them in chemical and petrochemical plants, oil and gas refineries, marine and offshore systems, power plants, and heat exchangers. They’re particularly suited for transporting corrosive fluids, acidic solutions, and seawater in high-pressure pipelines. Additionally, these fittings are utilized in pollution control equipment, nuclear applications, and more, showcasing their versatility and reliability in challenging environments.
