Tolu Fittings, a prominent manufacturer and supplier located in Abuja, Nigeria, specializes in high-quality Incoloy Buttweld Fittings that are crafted for outstanding performance and durability in tough industrial piping systems. These fittings are engineered to handle extreme temperatures, high pressures, and corrosive environments, making them perfect for critical applications in sectors like oil and gas, chemical processing, petrochemical, and power generation. Tolu Fittings prides itself on precision engineering, rigorous quality control, and prompt delivery, ensuring that customers receive reliable and long-lasting solutions. Their Incoloy Buttweld Fittings facilitate seamless installation, efficient flow management, and exceptional performance even in harsh operating conditions.
| Specifications | : | ASTM B366 / ASME SB366 |
| Size | : | Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″ |
| Standards | : | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | : | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
| Type | : | Seamless / Welded / Fabricated |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
| 825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
Made primarily from nickel, iron, and chromium, Incoloy Buttweld Fittings boast excellent resistance to oxidation, corrosion, and high-temperature scaling. These fittings are known for their superior mechanical properties, including high tensile and yield strength, toughness, and impact resistance, making them ideal for extreme operating environments. The buttweld design promotes smooth flow and minimizes turbulence, while precise forging and manufacturing processes improve grain structure and uniformity. Incoloy Buttweld Fittings are produced to meet international standards, ensuring reliable performance and structural integrity in challenging industrial conditions.
Tolu Fittings is a leading supplier of Incoloy Buttweld Pipe Fittings in Abuja, Nigeria. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy Pipe Fittings from Tolu Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Incoloy Buttweld Fittings offer numerous advantages, making them a preferred choice across industries. Their excellent corrosion resistance ensures durability in harsh environments, including high temperatures and chemical exposure. These fittings provide superior mechanical strength, reducing the risk of failure under pressure. The seamless construction enhances flow efficiency and eliminates weak points, ensuring long-term reliability. Incoloy’s resistance to oxidation and stress-corrosion cracking adds to its versatility, making it ideal for marine, chemical, and power industries. Easy to weld and install, these fittings also ensure leak-proof and robust connections.
Yes, custom sizes for Incoloy Pipe Fittings are available at Tolu Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@tolufittings.com.
These fittings find extensive use in oil and gas pipelines, chemical and petrochemical plants, refineries, and high-temperature process industries where corrosion resistance and mechanical strength are essential. They are also well-suited for power generation, desalination plants, offshore platforms, and various industrial machinery applications. Designed to ensure efficient fluid flow and endure aggressive environments, Incoloy Buttweld Fittings deliver safe, long-term, and dependable performance for critical infrastructure and demanding industrial systems.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
