Tolu Fittings stands out as a leading manufacturer and supplier in Abuja, Nigeria, specializing in top-notch Monel 400 Buttweld Fittings that are perfect for tough industrial tasks. These fittings are built to resist corrosion, boast impressive mechanical strength, and offer durability in both oxidizing and reducing environments. Designed for precise, leak-proof connections, Monel 400 Buttweld Fittings excel in high-pressure and high-temperature piping systems. Trusted by industries like chemical processing, marine, petrochemical, and power, these fittings promise reliable performance, a long lifespan, and excellent resistance to stress corrosion cracking. Tolu Fittings is committed to meeting international standards for quality, safety, and durability in every product.
| Specification Properties: | Monel 400 Pipe Fittings |
| Cmmonly Used Fittings Types | End Cap, Stub End, Bend, Tee, Reducer, Cross, Adapter, 4 Wye, Elbow |
| Flange Connection Type | Clamp End / End Bell/ Threaded/ Weld |
| Thickness Tolerance: | Schedule 20S To Schedule XXS |
| Length: | Normal Pipe Size (1⁄₂”) to Normal Pipe Size (48”) |
| Manufacturer Of Fittings Dimension Types: | ANSI B16.28, MSS-SP-43 Type A, JIS B2312, ANSI B16.9, MSS-SP-43 Type B, JIS B2313 |
| Standard Chart : | JIS, NPT, ISO, DIN, EN |
| Pressure Rating Chart : | 150# To 2500#. |
| Materials List: | Bronze, Copper, Iron (Ductile/Cast), Carbon Steel, Inconel, Monel, Hastalloy, Alloy Steel, Brass, Titanium, Chrome-molybdenum, Cupro-Nickel 90/10 & 70/30, Nickel, Nickel Alloys, Tantalum, Stainless Steel. |
Monel 400 Buttweld Fittings are made up of about 63% nickel and 28–34% copper, along with trace amounts of iron, manganese, and silicon to boost their mechanical properties. This special blend gives them remarkable resistance to corrosion from acids, alkalis, seawater, and hydrofluoric acid. On the mechanical side, Monel 400 boasts a tensile strength ranging from 550–700 MPa and a yield strength of 240–380 MPa, all while maintaining excellent ductility, toughness, and thermal stability. These characteristics make the fittings perfect for challenging industrial environments, ensuring they hold up under high stress, temperature, and corrosive conditions.
| The Chemical Composition of Monel 400 Pipe Fittings, % | |
|---|---|
| Iron | ≤2.50 |
| Sulfur | ≤0.024 |
| Silicon | ≤0.50 |
| Copper | 28.0-34.0 |
| Nickel | ≥63.0 |
| Carbon | ≤0.30 |
| Manganese | ≤2.0 |
| Tensile Strength, minimum | Yield Strength, minimum | Elongation, minimum | Hardness | ||
|---|---|---|---|---|---|
| Mpa | ksi | Mpa | ksi | % | HB |
| 550 | 80 | 240 | 35 | 40 | 110-150 |
Tolu Fittings is a leading supplier of Monel 400 Buttweld Fittings in Abuja, Nigeria. We offer an extensive range of Monel 400 Buttweld Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Monel 400 Pipe Fittings | N04400 | 2.4360 | NU-30M | NiCu30Fe | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 |
Choose Monel 400 Buttweld Fittings from Tolu Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Monel 400 Buttweld Fittings offer exceptional advantages, including superior corrosion resistance in seawater, acidic, and alkaline environments. They are highly durable, with excellent resistance to pitting, crevice corrosion, and stress corrosion cracking, ensuring reliable performance in harsh conditions. These fittings retain their strength and mechanical properties at elevated temperatures, making them suitable for high-pressure and high-temperature applications. Monel 400 is also known for its excellent weldability and machinability, facilitating seamless installation. Their versatility and long-term reliability make them a preferred choice for marine, chemical, and industrial applications.
Yes, custom sizes for Monel 400 Buttweld Fittings are available at Tolu Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@tolufittings.com
Tolu Fittings’ Monel 400 Buttweld Fittings are extensively utilized in sectors where corrosion resistance and strength are paramount. They’re commonly found in chemical processing, marine and offshore piping systems, desalination plants, oil and gas refineries, and power generation facilities. These fittings are particularly suited for piping systems that deal with acids, alkalis, saline water, and other aggressive chemicals at high temperatures and pressures. Their sturdy design guarantees leak-proof, durable connections, making them indispensable for critical applications.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
