Tolu Fittings, located in Abuja, Nigeria, stands out as a top-notch manufacturer and supplier of high-quality Monel Forged Fittings. Known for their exceptional corrosion-resistant products, Tolu Fittings offers a wide array of Monel fittings that are specifically designed for tough industrial applications. With a strong emphasis on precision manufacturing, quality control, and customer satisfaction, the company guarantees that every product meets international standards. Their Monel Forged Fittings are built to excel in harsh environments, providing remarkable durability and strength for sectors like chemical processing, marine engineering, oil and gas, and power generation, both in Nigeria and around the world.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
Monel Forged Fittings are mainly made up of nickel (about 63%) and copper (roughly 30–34%), along with trace amounts of iron, manganese, carbon, and silicon. This unique blend gives them outstanding resistance to seawater, acids, and alkalis. On the mechanical side, Monel boasts a high tensile strength of around 550 MPa and a yield strength close to 240 MPa. It retains impressive toughness and ductility, even in freezing temperatures. The alloy’s remarkable hardness, paired with its superior corrosion resistance, makes it perfect for high-pressure and high-temperature applications in demanding service conditions.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
Tolu Fittings is a leading supplier of Monel Forged Fittings in Abuja, Nigeria. We offer an extensive range of Monel Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Monel | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
Choose Monel Forged Fittings from Tolu Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Monel Forged Fittings offer several key advantages, including exceptional corrosion resistance, particularly in seawater and acidic environments. Their excellent resistance to pitting, crevice corrosion, and stress corrosion cracking makes them ideal for harsh conditions, such as marine and chemical processing applications. Monel fittings maintain their strength and integrity at elevated temperatures, offering superior durability in high-stress environments. They also possess excellent weldability and machinability, making installation and customization easier. With their long-lasting performance and ability to withstand extreme conditions, Monel Forged Fittings provide reliable solutions for critical industrial applications.
Yes, custom sizes for Monel Forged Fittings are available at Tolu Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@tolufittings.com
These Monel Forged Fittings are extensively used in industries that require exceptional corrosion resistance and robust mechanical performance. They are particularly suited for marine and offshore engineering, heat exchangers, and piping systems in chemical and petrochemical facilities. Additionally, these fittings find significant use in oil and gas refineries, pulp and paper industries, and power generation plants. Their capability to endure acidic and alkaline environments makes them ideal for managing seawater, brine, and other corrosive fluids. Monel Forged Fittings guarantee reliability, leak-proof performance, and a long service life, even in the most challenging industrial operations.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
