Tolu Fittings, a reputable manufacturer and supplier located in Abuja, Nigeria, proudly offers top-notch **Nickel Alloy 200 Forged Fittings** that are built to excel in even the toughest industrial settings. Crafted from high-purity nickel and utilizing cutting-edge forging techniques, these fittings guarantee remarkable strength, precision, and durability. Renowned for their exceptional resistance to alkalis and reducing agents, Nickel Alloy 200 Forged Fittings from Tolu Fittings are perfect for sectors like chemical processing, marine, oil and gas, and power generation, where corrosion resistance and mechanical integrity are absolutely essential.
| ASTM B564 – ASME SB564 | Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings |
| ASME B16.9 | Factory-Made Wrought Buttwelding Fittings |
| ASME B16.11 | Socket Welding and Threaded Forged Fittings |
| MSS SP-43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
Nickel Alloy 200 (UNS N02200) is a highly pure nickel-based alloy with a composition primarily consisting of 99% nickel, along with trace amounts of iron, copper, and other elements. This alloy offers excellent corrosion resistance, particularly in alkaline and acidic environments, and maintains good strength and ductility at both ambient and elevated temperatures. Mechanical properties include a tensile strength of 70-90 ksi, yield strength of 30-50 ksi, and elongation of around 35-50%. Nickel Alloy 200 is widely used in industries like chemical processing and electronics for its resistance to oxidation and thermal conductivity.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
|---|---|---|---|---|---|---|---|
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
These fittings are made up of over 99% pure nickel, with just a touch of iron, copper, and manganese. They boast a tensile strength of around 450 MPa and a yield strength of about 150 MPa, providing excellent ductility, weldability, and thermal conductivity. The alloy stands out with its superior resistance to caustic alkalis, neutral salts, and dry fluorine, while also maintaining toughness even in freezing temperatures.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Density (Kg.m-1) | 84.3 |
|---|---|
| Magnetic Permeability (20°C) | <1.005 |
| Curie Temperature (°C) | -90 |
| Young’s Modulus (N/mm2) | 179 x 103 |
| Specific Heat, 20°C (J.Kg-1.°K-1) | 418 |
| Specific Electrical Resistance, 20°C (?O.m) | 0.62 |
| Thermal conductivity,20°C (W.m-1.°K-1) | 17.5 |
| Mean coefficient of thermal expansion, 20-100°C (°K-1) | 13.4 x 10-6 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
Nickel Alloy 200 Forged Fittings from Tolu Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Nickel Alloy 200 Forged Fittings offer several advantages, including exceptional corrosion resistance, particularly in alkaline and mildly acidic environments, making them ideal for chemical processing and marine applications. They maintain high strength, good mechanical properties, and excellent weldability, ensuring durability and long service life. The alloys resistance to stress corrosion cracking and its ability to perform at elevated temperatures make it suitable for demanding applications. Furthermore, Nickel Alloy 200 has excellent thermal and electrical conductivity, enhancing its performance in electrical and heat exchanger systems, ensuring reliability and longevity in challenging environments.
Yes, custom sizes for Nickel Alloy 200 Forged Fittings are available at Tolu Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@tolufittings.com.
Nickel Alloy 200 Forged Fittings find their place in various applications, including caustic soda production, heat exchangers, condensers, marine systems, and chemical processing facilities. They are particularly suited for piping systems that deal with highly corrosive or high-temperature media. With their unique blend of purity, corrosion resistance, and mechanical strength, Nickel Alloy 200 Forged Fittings are a dependable choice for critical industrial applications that demand long-lasting performance and durability in harsh environments.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
