Tolu Fittings, a well-respected manufacturer and supplier located in Abuja, Nigeria, specializes in high-quality **Nickel Alloy 201 Pipe Fittings** that are built to withstand corrosion, provide strength, and ensure reliability even in the toughest industrial settings. These fittings are crafted using cutting-edge technology and top-notch raw materials, guaranteeing precision, durability, and consistent performance. With their remarkable resistance to caustic alkalis and reducing chemicals, Nickel Alloy 201 Pipe Fittings from Tolu Fittings are perfect for applications in the chemical processing, marine, and power generation sectors, where both purity and strength are crucial.
| Specifications | ASTM B366 / ASME SB366, ASTM B366 UNS N02201, ASME SB366 UNS N02201 | |
|---|---|---|
| Ni Alloy 201 Pipe Fittings size | Alloy 201 Seamless Butt Weld Fittings: 1/2″ – 10″ Alloy 201 Welded Butt Weld Fittings: 1/2″ – 48″ | |
| UNS N02201 Pipe Fittings Standards | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504 , BS4504, BS1560, BS10 | |
| Nickel Alloy 201 Fittings Available Thickness | Schedule 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 | |
| ASTM B366 UNS N02201 Buttweld fitting Main Types | Seamless / Welded / Fabricated | |
| ASME SB 564 201 Fittings Thread | NPT , BSPT, BSPP | |
| Nickel Alloy Ni201 Fittings Type | DN15-DN1200 | |
| End | Threaded, Welding, JIC | |
| 2.4068 Nickel Hydraulic Tube Fittings Pressure Rating |
|
|
| Connection | Welding | |
| UNS 2201 Buttweld Fitting Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc | Application |
|
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | ||
Made up of over 99% pure nickel, these fittings have a controlled carbon content (maximum of 0.02%) that boosts their thermal stability and resistance to graphitization. They boast a tensile strength of about 403 MPa and a yield strength of roughly 147 MPa, along with impressive ductility and toughness. This unique composition provides exceptional corrosion resistance in alkaline and neutral salt environments, as well as excellent mechanical stability at high temperatures.
| Nickel 201 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| Balance | 0.15 max | – | 0.35 max | 0.35 max | 0.40 max | – | 0.01 max | 0.25 max | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
Tolu Fittings is a leading supplier of Nickel Alloy 201 Pipe Fittings in Abuja, Nigeria. We offer an extensive range of Nickel Alloy 201 Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Nickel 201 | N02201 | 2.4068 | – | LC-Ni 99 | NW 2201 | NA 12 | НП-2 |
Nickel Alloy 201 Pipe Fittings from Tolu Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Nickel Alloy 201 pipe fittings offer excellent corrosion resistance, particularly in acidic environments, making them ideal for chemical processing, petrochemical, and marine applications. Their high electrical and thermal conductivity enhances performance in heat exchangers and electrical components. Nickel Alloy 201 also provides good weldability, fabrication ease, and stress-corrosion cracking resistance. It maintains mechanical strength at elevated temperatures, ensuring durability in high-heat environments. Additionally, its non-magnetic properties make it suitable for specialized applications where magnetism could be an issue, offering versatility and reliability in harsh conditions.
Yes, custom sizes for Nickel Alloy 201 Pipe Fittings are available at Tolu Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@tolufittings.com.
Nickel Alloy 201 Pipe Fittings find extensive use in various industries, including food processing, synthetic fiber production, caustic soda manufacturing, and marine engineering. They are particularly suited for heat exchangers, condensers, and piping systems that deal with highly corrosive or high-temperature fluids. Their blend of purity, corrosion resistance, and mechanical strength makes them the go-to choice for critical industrial applications where long-lasting reliability and performance are essential.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
