Tolu Fittings, a well-respected manufacturer and supplier located in Abuja, Nigeria, specializes in top-notch **Stainless Steel 316H Buttweld Fittings** that are crafted to excel in high-temperature and corrosive settings. Using cutting-edge technology and high-quality raw materials, these fittings promise durability, precision, and outstanding mechanical strength. With their enhanced carbon content and superior creep resistance, Tolu Fittings’ Stainless Steel 316H Buttweld Fittings are perfect for industries like petrochemical, power generation, and chemical processing, where reliability and longevity are essential.
| Specifications | ASTM A403 / ASME SA403 |
| Size | Seamless Butt Weld Fittings: 1/2″ – 24″, Welded Butt Weld Fittings: 1/2″ – 48″ |
| Standards | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
| Type | Seamless / Welded / Fabricated |
These fittings are made up of chromium (16–18%), nickel (10–14%), and molybdenum (2–3%), along with a higher carbon content that boosts tensile strength and stability at high temperatures. They boast a tensile strength of around 515 MPa and a yield strength of about 205 MPa, all while maintaining excellent ductility and resistance to oxidation. The addition of molybdenum enhances their ability to resist pitting and crevice corrosion, while the increased carbon content improves their mechanical properties in elevated temperature conditions.
| Grade | 316/316H/316L | |
|---|---|---|
| min | max | |
| C | – | 0.035 |
| Mn | – | 2.0 |
| Si | – | 0.75 |
| P | – | 0.045 |
| S | – | 0.030 |
| Cr | 16.0 | 18.0 |
| Mo | 2.0 | 3.0 |
| Ni | 10.0 | 14.0 |
| N | – | – |
Tolu Fittings is a leading supplier of Stainless Steel 304L Buttweld Fittings in Abuja, Nigeria. We offer an extensive range of Stainless Steel 304L Buttweld Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 304L Buttweld Fittings from Tolu Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Stainless steel 316H Buttweld Fittings provide exceptional corrosion resistance, especially in high-temperature environments, making them ideal for chemical, petrochemical, and marine applications With high strength and durability these fittings maintain structural integrity in high-pressure and high-pressure conditions. The advanced carbon content of the 316H grade increases its strength at elevated temperatures, making it suitable for heat exchanger and boiler systems. These materials also exhibit excellent weldability and resist pitting, crevice corrosion, and chloride stress corrosion, providing durability and reliable performance in harsh environments.
| Nominal Pipe Size (inches) | Outside Diameter | 45°Elbows | 90° Elbows | 180° Returns | ||||
|---|---|---|---|---|---|---|---|---|
| Long Radius | Long Radius | Short Radius | Long Radius | |||||
| (mm) | (inches) | Center to Face (inches) | Radius (inches) | Center to Face (inches) | Center to Face (inches) | Center to Center (inches) | Back to face (inches) | |
| 1 | 33.4 | 1.315 | 7/8 | 1 1/2 | 1 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.660 | 1 | 1 7/8 | 1 1/4 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.900 | 1 1/8 | 3 | 2 1/4 | 1 1/2 | 4 1/2 | 3 1/4 |
| 1/2 | 21.3 | 0.840 | 5/8 | 1 1/2 | – | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.050 | 7/16 | 1 1/8 | – | 2 1/4 | 1 11/16 | |
| 2 | 60.3 | 2.375 | 1 3/8 | 4 | 3 | 2 | 6 | 4 3/16 |
| 2 1/2 | 73.0 | 2.875 | 1 3/4 | 5 | 3 3/4 | 2 1/2 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.500 | 2 | 6 | 4 1/2 | 3 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4.000 | 2 1/4 | 7 | 5 1/4 | 3 1/2 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.500 | 2 1/2 | 8 | 6 | 4 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 3 1/8 | 10 | 7 1/2 | 5 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 3 3/4 | 12 | 9 | 6 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 5 | 12 | 12 | 8 | 24 | 16 5/16 |
| 10 | 273.1 | 10.750 | 6 1/4 | 15 | 15 | 10 | 30 | 20 3/8 |
| 12 | 323.9 | 12.750 | 7 1/2 | 18 | 18 | 12 | 36 | 24 3/8 |
Yes, custom sizes for Stainless Steel 304L Buttweld Fittings are available at Tolu Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@tolufittings.com.
Stainless Steel 316H Buttweld Fittings are commonly utilized in industries that require both corrosion resistance and high mechanical strength. They are ideal for applications such as heat exchangers, boilers, pressure vessels, refinery systems, and thermal processing equipment. In the chemical and petrochemical sectors, they perform exceptionally well in chloride-rich and acidic environments. These fittings are also well-suited for marine and oil and gas applications. Their excellent weldability, stability during thermal cycling, and resistance to harsh media make them a top choice for critical industrial piping systems.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
